• Core Application
The 42,000L aluminum alloy fuel tank trailer is our very popular products, the fuel tank and chassis details are perfectly designed. Compared with the carbon steel fuel tank, the aluminum fuel tank trailer has less weight and more load. The core application is similar with the carbon steel fuel tank, mainly used for fuel oil transportation. Because of the less weight and economic operation, the aluminum alloy fuel tank is very popular among the logistic companies.
• Large Volume, High Strength
This product is made of high-quality ALCOA alloy. Its total volume is 42,000 liters. Its hardness and toughness are much stronger than normal aluminum alloys, so it has a longer service life.
• Tank Parts
The aluminum alloy fuel tank parts include the manhole cover, discharge valve, foot valve also named emergency valve, bottom valve, vapor recovery system, optical sensor, bottom valve pneumatic control board, etc. We have several brands in different price level and quality level, we have China brand Jialong, American brand CIVOCAN, German brand EMCO, French brand PEROLO, all of them are good and reliable quality.
Advantages:
• First-class Quality, Reasonable Price
Our product is designed with ALCOA alloy which provides higher hardness and better toughness. Strict factory inspection is conducted to maintain the quality. Moreover, our products are available at a reasonable price.
• Corrosion-Resistant
Our products are corrosion-resistant and frequent painting is unnecessary. Thus, maintenance costs are low and the surface is easy to clean.
• Flexible Configuration
The shape of the tank can be chosed for customers' preference.
Specifications:
| Dimension | 12000*2500*3750mm |
| GVW./Kerb Wt. | 45000 / 7500 kg |
| Fifth Wheel Load | 31000 kg |
| Axles | 3 Axles |
| Landing Legs |
JOST/FUWA brand; heavy duty; mechanical 2-speed manual operation; 28,000 kg per pair |
| Suspension System | Mechanical suspension/ air bag suspension |
| King Pin | JOST brand 2 inches bolt in king pin |
| Tyre | 11R 22.5 |
| Tank Shape | Square round shape |
| Total Volume | 42,000L |
| Tank Material | ALCOA 5083 |
| Manhole | 20 inches aluminum type with breath valve |
| Mudguards | Heavy duty mudguard with rubber mud-flaps |
| Bumpers |
Side bumper mounted between landing gear and first axle; Rear bumper is European standard |
| Brake | Dual circuit pneumatically operated |
| Electric System | 24V lighting system. 7-pole distribution cable. |
| Options | Emergency valve |
| Flow meter | |
| Bottom loading system | |
| Foldable handrail | |
| Epoxy coating inside the tanker | |
| Configuration | |
 |
|
Shipping:
Complete Chassis sand blasting to clean rust, 1 coat of anti-rust prime,2 coats of final pain
Roll on roll off (RORO) ship
It's the ship to transport cars and trucks, which has power wheel, it's the best way of truck transportation.
Bulk carrier ship
It's the ship to transport grain, coal, ore, salt, cement ,etc, dry and bulk goods, can also used to transport trucks,price is cheap, but the truck always be put on the deck, sea water will damage the truck painting.
Container ship
It's well-known shipping way, and also the highest cost among these three ways. Few sea port only container ship can arrive, so sometimes, we have to use container ship.
