Blue Color Curtain Side Flatbed PVC Tarpaulin High Strength Steel Structure High Strength Cord Fabric

Blue Color Curtain Side Flatbed PVC Tarpaulin High Strength Steel Structure High Strength Cord Fabric

Description:

• Practical Application

Since the left, right and rear of the curtain sliding trailer can be opened, it is convenient to complete the cargo work by the simplified process and disconnectable tarpaulin. The cheap tarpaulin can reduce the production cost and improve the market competitive strength. The curtain sliding trailer was ever the dominant trailer of road transport and was in vogue overseas.

Advantages:

• Sealed Carriage

1. The frame of the carriage welded by high-quality steels has a high strength and sealing property;

2. Four bars and locks are equipped on the rear door.

•Slidable Curtain

The top and both sides of the carriage are covered by high-strength cord fabric. They can slide forward and backward. Hence, goods can be loaded by a crane or a forklift.

Specifications:

Dimension
Overall Dimension	14000X2500X3850
Tare Weight	8600KGS
Running Gear
Chassis	Heavy duty and extra durability designed I beam by high tensile steel Q345B; Welded by automatic submerged arc processes; Top flange 14mm, width 140mm, middle flange 6mm; bottom flange 16mm, width 140mm.
Axle	3 axle, FUWA brand, 13Ton capacity
Suspension	Mechanical suspension
Spring	Leaf spring
King Pin	JOST kingpin, 2 inches
Landing Gear	JOST landing gear, manual operation, 2 speed
Wheel Rim	Steel wheel rim 9.0-22.5
Tire	Tubeless tire 12R22.5
Braking System	WABCO RE 6 relay valve; T30/30+T30 spring brake chamber; 40L air tanks
Painting	Complete chassis sand blasting to clean rust; 1 coat of anti-corrosive prime, 2 coats of final paint
Curtain Parts
Curtain Material	PVC curtains, fitted with buckles
Slide Rails	Aluminum alloy double slide rails
